The AMSEC AM3020E5 45-minute fire-rated security safe is one of three models that conveniently protect your important documents, cash, and other valuables at home. The AMSEC Model AM3020E5 home security safe series offers an unbeatable value, featuring a gray fabric interior including a back-cover and firewalls.
For security, the AMSEC home security safe includes a 12 gauge solid steel shell with a 1-1/8" door that is recessed. The door thickness includes 1/4" steel with the balance of fire insulating material. Also featured are five active 1-1/4" bolts in a three-way configuration along with the ESL5 electronic lock with an illuminated keypad standard. There are also 4 anchor holes that increase the forcible entry protection when used.
The AMSEC home security safe features a 45-minute fire rating which means it will withstand an exterior heat temperature of 1200 for 45 minutes without the interior temperature exceeding 350 degrees F. This is not bad for a home safe in this price range. The exterior paint is the traditional AMSEC deep blue textured finish and a raised American Security logo in black nickel hardware on the door. The interior shelves are gray fabric and add function and beauty to the interior.
Along with the blue textured finish, the AMSEC AM3020E5 home security safe has external hinges that provide complete interior access and allow the door to be opened a full 180 degrees. There is an "L" handle on the door. These features compliment any trophy room or den, providing a handsome look.
Contact one of our security specialists at Safe & Vault Store by calling 800-207-2259.
If you are an AMSEC fan, you will want to add the AMSEC AM3020E5 45-minute fire-rated security safe to your collection of quality products in your home.
AM Series Features:
*Please note that use of a residential safe in a commercial application will void the warranty. Check out the BFS2815E1 if you're using this for business purposes.
| Feature | AMSEC AM3020E5 | AMSEC AM3020PLUS |
|---|---|---|
| Outside Dimensions | 30.00" H × 20.00" W × 20.00" D (Add 2" for handle) | 30.00" H × 20.00" W × 20.00" D (Add 2" for handle) |
| Inside Dimensions | 27.25" H × 16.50" W × 14.00" D | 27.25" H × 16.50" W × 14.00" D |
| Interior Cubic Feet | 3.64 | 3.64 |
| Weight | 230 lbs | 230 lbs |
| Body Construction | 12-gauge solid steel body | 12-gauge solid steel body |
| Door Construction | ¼" solid steel plate with recessed design for pry resistance | ¼" solid steel plate with recessed design for pry resistance |
| Lock Type | AMSEC ESL5 electronic lock with illuminated keypad | AMSEC ESL5 electronic lock with illuminated keypad |
| Bolt Work | 3-way bolt work with five 1¼" chrome-plated locking bolts | 3-way bolt work with five 1¼" chrome-plated locking bolts |
| Fire Rating | 45 minutes at 1200°F (interior temperature below 350°F) | 45 minutes at 1200°F (interior temperature below 350°F) |
| Fire Certification | ETL tested | ETL tested |
| Anchoring | Four pre-drilled anchor holes with hardware included | Four pre-drilled anchor holes with hardware included |
| Shelves | Two adjustable shelves | Two adjustable shelves |
| Warranty | 1-year parts and labor | 1-year parts and labor |
| Finish | Textured gray finish | Gloss white finish |
| Interior | Fabric-lined interior | Upgraded quilted interior with LED lighting |
| Additional Features | — | Built-in LED interior lighting and modern white finish for premium appearance |
Yes. Free delivery is included on every safe we sell, anywhere in the lower 48 states. The specific delivery method depends on the safe's weight: small package delivery for under 150 lbs, curbside, or garage delivery for heavier safes. See full shipping details →
Shipping timelines vary by product. Check the availability status at the top of this page for the estimated ship date. Once shipped, transit time typically runs 5–10 business days, depending on your location. You'll receive tracking when the safe leaves the warehouse. Safes under 150 lbs ship via UPS or FedEx Ground, no appointment needed. Safes weighing 150 lbs or more ship via freight (LTL); the freight carrier will contact you directly to schedule a delivery appointment once the safe reaches your local terminal.
We don't provide inside delivery directly, but we work with third-party installers across the country who do. Here's how it works: call us at 800-207-2259 for a recommendation in your area, and we'll provide the names and phone numbers of installers we've worked with. You contact the installer directly to arrange pricing for delivery and installation. Once you've agreed on a price, place your order with us using the installer's address as the shipping destination. The installer receives the safe, inspects it, and schedules your final delivery appointment. Some installers prefer to pick the safe up directly from the freight terminal. See inside delivery details →
Check the product's exterior dimensions (listed above) against your narrowest passage, interior doorways, stair landings, and tight turns. Most people remove the safe from the pallet before moving it indoors, so the safe's actual dimensions are what matter for doorways. Standard interior doorways (30–32" clear) accommodate most residential safes, but measure before ordering. Call us if you're uncertain. See where to locate your safe →
Electronic locks: yes; it takes about 30 seconds. Instructions are included with your safe. Mechanical dial locks: no, changing a dial combination requires a licensed safe technician. Important: attempting to change a dial combination yourself (or having an unlicensed locksmith do it) voids the lock warranty. A licensed safe tech maintains the warranty. See lock operating instructions →
Call us immediately — while you have 24 hours to report damage, calling right away gets the claim filed faster. Take photos of the damage and packaging before moving anything. For minor cosmetic damage, we typically send touch-up paint plus a partial refund. For significant damage, we send replacement parts or arrange a full replacement. Order Protection (optional at checkout) speeds refund payouts to 48–72 hours vs. 30–60 days through standard freight claims; replacement safes ship on the manufacturer's normal timeline regardless. See receiving your safe →
We offer a 30-day return policy on unused, in-original-condition products. The return freight for a heavy safe is substantial, so we strongly encourage you to call us before ordering if you're unsure about fit or configuration. See full return policy →
Yes. Call us Monday–Friday, 8am–5pm Pacific at 800-207-2259. You have two options: we can take the full order by phone (we pause the call recording before you read your card number, so payment info is never stored), or we can build your order and email you a payable invoice link so you can enter your own payment details securely.
